REMA

Rema Connector 95505-01 DIN 320 A - 70mm² - Plug

MPN: 9550501 / 108957
(0)
€29,99
En existencia
Ships within 2 hours
Original REMA product

This is a genuine REMA product. All items sold are brand new and delivered in the manufacturer’s original, unopened packaging.

Free shipping available
100% secure payments
Industry leading quality

Got questions? Need a Quotation?

Feel free to get in touch

Ask an expert!

Correo electrónico +358 (0) 45 490 4545

REMA 95505-01 for DIN320 70mm² - Plug

Original REMA EURO DIN 320A / 70 mm² plug with grey coding, acid-resistant 108957 / 9550501 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)

95505-01 includes these parts:

  • 1x housing, 1x lock part, 1x coding pin (grey), 1x cable clamp set
  • 2x main contacts 70 mm², plug side

This is a Complete connector set with battery acid-resistant housing.

Extra accessories are available, such as extra auxiliary and pilot contact sets, handles, air pipes.

Housing material – IMPORTANT CLARIFICATION

🔹 This is the Battery Acid Resistant, Dark Grey housing version

  • Material: PP CoPo GF30 (copolymer polypropylene)

  • Battery acid-resistant

  • UL-tested version

  • Recommended for demanding battery and traction applications

👉 Only the housing material differs between the black and dark grey versions. All electrical and mechanical connector parts are identical.

** As an alternative, a complete black housing version is available under part number 75500-01 which features a fully black housing made from shock-resistant polyamide (PA), offering increased mechanical strength and improved impact resistance.

Only the housing material is different between these two versions and to note the dark-grey version is the one the UL -tests are made with.
  • Tipo Battery Connector
  • MPN 9550501 / 108957

Documentation Availability
Full technical documentation including detailed product datasheets, 3D STEP files, dimensional drawings, declarations of conformity and other certificates is available upon request.

Please contact our technical sales department at sales@oemnordic.com.
Certain controlled documents are provided directly to customers and are not distributed publicly online.
