Micropower | DC/DC Converter 48-24 200W PP, MPN: 0060333

DC-DC Converter Isolated 48 V to 24 V

This isolated DC-DC converter from Micropower Group is designed to convert a wide DC input range (33–65 V DC) into a stable 24 V DC output with high efficiency and robust performance. It uses advanced switching technology to achieve excellent efficiency, making it suitable for industrial, vehicle, and mobile power systems.

Key Specifications

• Input Voltage: 33–65 V DC
• Output Voltage: 24 V DC nominal (≈24.5 V)
• Output Power: 200 W
• Efficiency: >96 %
• Isolation: Galvanically isolated
• Ingress Protection: IP21 rated housing
• Connections: 6.3 mm Fast-on terminals
• Dimensions: 116 × 88 × 18 mm
• Weight: ~0.2 kg

Main Features

• Wide Input Range: Designed to work with 33–65 V DC sources for flexible use in various systems.
• High Efficiency: Modern switching design reduces power loss and heat.
• Galvanic Isolation: Provides electrical separation for safety and reduced noise.
• Compact Industrial Design: Space-saving format for use in cabinets and mobile assemblies.
• Built-in Protection: Internal safeguards against wrong polarity and short-circuit conditions.

Protection Functions

• Reverse polarity protection to help prevent installation damage.
• Short-circuit protection for enhanced reliability.
• Overload protection under excessive load conditions.



  Typical Applications

• Industrial automation and control systems
• Mobile and vehicle power systems
• Battery-powered equipment
• Telecommunications power supplies
• Control panel power conversion

Installation & Integration

• Fast-on terminal connections for straightforward setup.
• Compact and lightweight design integrates easily in tight spaces.
• Reliable conversion for demanding industrial use.
